Description
TufGel 332 is a clear, tough, moderately cross-linked silicone elastomer, which has good room temperature cure adhesion to many substrates. This material also has enhanced flame retardant properties compared to standard gels. Silicone gels are used to provide protection from vibration and thermal or mechanical shock. Silicone gels also provide excellent moisture protection.
KEY FEATURES
- One to one mix ratio
- High strength
- Dispensing equipment not necessary
- Non-yellowing catalyst system
- Good adhesion to many substrates including glass, aluminum and copper with primer
| UNCATALYZED | |||||
| TEST | TufGel 332 A | TufGel 332 B | |||
| Appearance | Transparent | Transparent | |||
| Viscosity | 820 cps | 750 cps | |||
| Specific Gravity | 0.97 | 0.97 | |||
| CATALYZED | |
| MIX RATIO 1:1 | |
| TEST | RESULT |
| Gel Time at 25ºC * | 5 Hours |
| CURE PROPERTIES | |
| Cure Profile | 30 minutes at 150ºC |
| 60 minutes at 100ºC | |
| 24 hours at 25ºC | |
| Durometer, Shore 00, 30 minutes at 150ºC | 30-55 |
| ADDITIONAL PROPERTIES | |
| Useful temperature range. | -55°C – 204°C |
| Adhesion | Silicone gels have a tacky surface and will form a mechanical bond to most substrates. |
| Electrical Properties | Excellent dielectric strength |
